製品詳細
起源の場所: ジナン、シャンドン
ブランド名: Jiu Runfa
証明: IOS9001
モデル番号: MDF 吸音パネル S77 レッドオーク
支払及び船積みの言葉
最小注文数量: 1㎡
価格: $1
パッケージの詳細: プラスチック密封包装
受渡し時間: 5-14勤務日
支払条件: L/C、T/T、ウェスタンユニオン、マネーグラム
供給の能力: 100000㎡
製品名 : |
音響パネル |
材料構成: |
100％ポリエステル繊維（PET）または木毛＋セメント |
製造工程: |
ホットプレス成形；湿式混合セメント接着 |
密度: |
120〜200kg/m3（PET） / 300〜450kg/m3（木毛） |
音響評価: |
NRC 0.75–0.95 (ASTM C423 または ISO 354 に従ってテスト) |
吸音範囲: |
125Hz～4000Hzの吸音効果があります。 |
可燃性評価: |
クラス A / B1 ASTM E84、EN 13501-1、GB 8624-2012 に準拠 |
熱伝導率: |
0.040～0.045W/m・K |
ホルムアルデヒドの放出: |
E0（≤0.5 mg/L） / EN 717-1準拠 |
水分率: |
≤ 0.8%(PET) |
吸水性: |
<1% 寸法変化 / 寸法変化率 |
製品名 : |
音響パネル |
材料構成: |
100％ポリエステル繊維（PET）または木毛＋セメント |
製造工程: |
ホットプレス成形；湿式混合セメント接着 |
密度: |
120〜200kg/m3（PET） / 300〜450kg/m3（木毛） |
音響評価: |
NRC 0.75–0.95 (ASTM C423 または ISO 354 に従ってテスト) |
吸音範囲: |
125Hz～4000Hzの吸音効果があります。 |
可燃性評価: |
クラス A / B1 ASTM E84、EN 13501-1、GB 8624-2012 に準拠 |
熱伝導率: |
0.040～0.045W/m・K |
ホルムアルデヒドの放出: |
E0（≤0.5 mg/L） / EN 717-1準拠 |
水分率: |
≤ 0.8%(PET) |
吸水性: |
<1% 寸法変化 / 寸法変化率 |
Acoustic Panels Product Introduction
Acoustic panels are high-performance sound-absorbing materials designed to reduce noise, echo, and reverberation in various indoor environments. Made from eco-friendly polyester fiber, foam, wood, or fabric-wrapped composites, these panels effectively enhance acoustic comfort while improving overall interior aesthetics.
Engineered with excellent sound absorption coefficients (NRC 0.8–1.0), our acoustic panels are widely used in offices, conference rooms, studios, home theaters, classrooms, hotels, gyms, and industrial noise-control areas. They minimize unwanted reflections and create clearer, more focused sound environments.
Our panels are lightweight, easy to install, and available in multiple shapes, colors, and thickness options to match diverse design requirements. With fire-resistant, moisture-resistant, and environmentally safe materials, they offer long-lasting performance and stable acoustic results.
Whether for professional sound engineering or everyday noise reduction, our acoustic panels deliver reliable, eco-friendly, and aesthetically pleasing solutions for modern interior spaces.
Acoustic Panels Product Specifications
| Item | Technical Specification |
|---|---|
| Product Name | Acoustic Panel |
| Material Composition | 100% Polyester Fiber(PET) or Wood Wool + Cement |
| Production Process | Hot-press Forming ；Wet-mixed Cement Bonding |
| Density | 120–200 kg/m³(PET) / 300–450 kg/m³(Wood Wool) |
| Acoustic Rating | NRC 0.75–0.95(Tested according to ASTM C423 or ISO 354) |
| Sound Absorption Range | Effective sound absorption at 125 Hz – 4000 Hz. |
| Flammability Rating | Class A / B1 According to ASTM E84, EN 13501-1, GB 8624-2012 |
| Thermal Conductivity | 0.040–0.045 W/m·K |
| Formaldehyde Emission | E0(≤0.5 mg/L) / EN 717-1 compliance |
| Moisture Rate | ≤ 0.8%(PET) |
| Water Absorption | <1% Dimensional Change / Rate of Dimensional Change |
| Compressive Strength | ≥ 120 kPa(PET) |
| Tensile Strength | ≥ 90 kPa |
| Surface Finishing | Plain / Grooved / Beveled Edge / Fabric Wrapped |
| Standard Sizes | 1220×2420 mm, 600×600 mm, 600×1200 mm(Customization supported) |
| Thickness | 9 mm / 12 mm / 24 mm / 25 mm / 50 mm |
| Color Options | 40–60 Color Options / 40–60 colors available (customization supported) |
| Installation | Adhesive / Aluminum Frame / Z-Clips / |
| Environmental Certifications | SGS / REACH / RoHS Available |
| Applications | Studios, Offices, Theaters, Schools, Hotels |
Acoustic Panels Features
Superior Sound Absorption Performance
Effectively reduces noise and controls echo, with a Noise Reduction Ratio (NRC) of 0.75–0.95.
Wide Frequency Absorption Range
Performs excellently across a frequency range of 125 Hz to 4000 Hz, suitable for speech, music, and general indoor acoustic treatment.
Fire Resistant
Meets Class A/B1 fire resistance standards (ASTM E84, EN 13501-1, GB 8624), ensuring enhanced safety.
Environmentally Friendly and Non-Toxic
Made from recyclable polyester fibers, low in VOCs, and with formaldehyde content meeting E0 standards, suitable for schools, offices, and homes.
Lightweight and Easy to Install
Can be mounted on walls or ceilings using adhesives, frames, or clips.
Durable and Stable
High-density materials ensure excellent impact resistance, stability, and lifespan.
Humidity and Thermal Stability: Low water absorption (<1%), maintaining stability in various indoor environments; thermal conductivity of 0.040–0.045 W/m·K.
Aesthetically pleasing and Customizable Designs: Available in 40–60 colors, various patterns, perforated or grooved finishes, and customizable shapes.
Safe and Comfortable Indoor Environment: Free of fiberglass dust, odorless, and hypoallergenic, making it ideal for public spaces, offices, and homes.
Acoustic Panels Application Cases
Restaurant Acoustic Improvement
Client Need: Reduce dining noise.
Problem: Customers complained environment too noisy.
Solution: Added ceiling baffle acoustic panels.
Effect: Comfort and customer satisfaction increased.
About Us
Shandong Jiurunfa Acoustic Materials Co., Ltd. is a professional manufacturer specializing in high-performance acoustic solutions for global markets. With over 10 years of experience in the industry, we focus on the research, production, and customization of polyester fiber acoustic panels, fabric-wrapped panels, wood wool cement boards, and other architectural acoustic materials.
