Highlight:
eco friendly coated fabric
, flexible coated fabric for textiles
, wear resistant coated fabric
Thickness: |
0.15 Mm – 2.0 Mm |
Width: |
1.00m / 1.50m / 2.00m / 3.20m |
Tensile Strength (Warp）: |
800–4500 N/5cm |
Tensile Strength (Weft): |
500–3500 N/5cm |
Item Typical Range / Value Description Base Fabric Material Shandong, China - Brand Name JRF - Base: |
80–600 N |
Tear Strength (Weft): |
80–600 N |
Hydrostatic Pressure: |
1000–10000 MmH₂O |
Temperature Resistance: |
-30℃ To +80℃ (Up To -50℃ Optional) |
Flame Retardant Grade: |
NFPA 701 / B1 / M1 |
Breathability: |
500–5000 G/m²·24h |
Color Options: |
White, Black, Gray, Green, Custom (Pantone Support) |
Surface Finish: |
Matte / Semi-matte / Glossy / High-gloss |
Mold Resistance: |
Grade 0 – 5 (Up To 3A Industrial Standard) |
UV Protection: |
UPF 30+ / 50+ / 100+ |
Service Life: |
3 – 10 Years |
Environmental Certification: |
ROHS / REACH / OEKO-TEX / EN-71 |
coated Fabric Product ntroduction
Coated fabric is a funcionalcomposite material made by coaing polyester,coton,fiberglass cloth, or ther simlar materials with Pvc, PU,PE, siicne, or acplic materials.ltcombines the mechanical strength of the texle base withthe protective properies of the coaing, achieving a variety of characteristics such as waterproofing, oil resistance.abrasion resistance, flame relardancy,tear resistance, anibacterial properies,and UV resistance. tis widely usd in industrial equipment protecion,medical dressings, outdoolproducts.transport2nctocnnica teyiec
Coated fabric product parameters
| Item |
Typical Range / Value |
Description |
| Base fabric material |
Shandong, China |
- |
| Brand Name |
JRF |
- |
| Base Fabric |
Polyester, Cotton, Nylon, Fiberglass, Blended |
Selected according to application |
| Coating Type |
PVC, PU, PE, EVA, PTFE |
Different coatings for different performance |
| Surface Treatment |
Waterproof, Fireproof, Anti-UV, Anti-static, Anti-mildew, Abrasion-resistant |
Customizable functions |
| Weight (g/m²) |
150 – 1200 (Common: 300–600 g/m²) |
Customizable |
| Thickness |
0.15 mm – 2.0 mm |
Can be increased by lamination |
| Width |
1.00m / 1.50m / 2.00m / 3.20m |
Supports customized cutting |
| Tensile Strength (Warp) |
800–4500 N/5cm |
EN ISO 1421 Standard |
| Tensile Strength (Weft) |
500–3500 N/5cm |
EN ISO 1421 Standard |
| Tear Strength (Warp) |
80–600 N |
ASTM D751 Standard |
| Tear Strength (Weft) |
80–600 N |
ASTM D751 Standard |
| Hydrostatic Pressure |
1000–10000 mmH₂O |
Waterproof rating |
| Temperature Resistance |
-30℃ to +80℃ (Up to -50℃ optional) |
Outdoor performance |
| Flame Retardant Grade |
NFPA 701 / B1 / M1 |
Certificates available |
| Breathability |
500–5000 g/m²·24h |
PU/TPU breathable |
| Color Options |
White, Black, Gray, Green, Custom (Pantone support) |
Customizable |
| Surface Finish |
Matte / Semi-matte / Glossy / High-gloss |
Optional |
| Mold Resistance |
Grade 0 – 5 (Up to 3A Industrial Standard) |
Anti-mildew test |
| UV Protection |
UPF 30+ / 50+ / 100+ |
For outdoor use |
| Service Life |
3 – 10 years |
Depends on usage environment |
| Environmental Certification |
ROHS / REACH / OEKO-TEX / EN-71 |
Reports available |
Features of coated fabric products
Coated fabnic posseses high strengh, waterproof, corosion-resisitanl, weaher-resistant, customizable fame-retardant and enronmentaly friendly properies,making itsuitalblefor various industrial and outdoor environments. it is a cost-effective, long-lasting, and fexible functional material.
Coated Fabric Product Cases
Cycling Gear Brand – Addressing Pain Points in Commuting Raincoats: The brand's original commuting raincoats suffered from issues such as water seepage through seams, stuffiness after 20 minutes of cycling, and pilling and damage after 3 months of friction.
The upgraded version features a high-elasticity, abrasion-resistant double-coated fabric: 40D polyester base material + TPU waterproof coating (IPX6) with heat-sealed edges, and a breathable microporous coating on the other side (6000g/㎡·24h). Abrasion-resistant PU coating (over 50,000 abrasion resistance) is added to high-friction areas.
After the upgrade, water seepage complaints decreased by ≤3%, stuffiness feedback decreased by 88%, lifespan was extended to 18 months (3 times the original), and the positive review rate increased from 72% to 95%, driving an 80% increase in the brand's cycling gear sales.
About Us
Jiurunfa Chemical Technology Co., Ltd., relying on its dual core advantages of "R&D-driven development + strict quality control," has established an R&D team composed of materials science experts and chemical engineers. Equipped with advanced coating process laboratories and testing centers, it can achieve independent innovation across the entire chain, from substrate selection and coating formulation development to production process optimization. Currently, it holds over 20 patented technologies, and its core coating technologies cover diverse functions such as waterproofing and leak prevention, antibacterial and stain resistance, breathability and moisture permeability, high temperature and wear resistance, and low allergen and environmental friendliness. It can customize coated fabric products with different coating systems such as PU, PVC, TPU, and silicone according to customer needs.
